Fujitsu SP-1125N User Manual

3 Remove the jammed document.
ATTENTION
● Make sure to check the documents and the paper path thoroughly. Remove any metal objects such as
staples or paper clips to prevent paper jams.
● Be careful not to damage the glass surface and the guides when removing documents with metal
objects such as staples or paper clips.
4 Close the ADF.
For details, refer to How to Close the ADF (page 35).
CAUTION
Be careful not to get your fingers caught when closing the ADF.
ATTENTION
● Confirm that the ADF is closed properly. Otherwise, documents may not be fed into the ADF.
● Occasionally when scanning is complete or canceled, documents may remain in the ADF without any
error message displayed. In that case, follow steps 1 through 4 above to remove the documents.
● To continue scanning, check which page you want to resume from, and load the document in the ADF
paper chute (feeder) again.
Troubleshooting
88

Fujitsu SP-1125N Specifications

General

Color scanning	Yes
Maximum scan size	210 x 297 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Scanner type	ADF scanner
Product color	Gray
Built-in display	No
Sensor type	CMOS dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	PDF
Daily duty cycle (max)	- pages
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input voltage	100 - 240 V
Power supply type	AC
Power consumption (off)	0.3 W
Power consumption (sleep)	2 W
Power consumption (typical)	18 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	135 mm
Width	298 mm
Height	133 mm
Weight	2500 g
