Fujitsu SP-1125N User Manual

Conditions Required to Accurately Detect Overlapped Documents (Multifeed)
Multifeed is an error that occurs when two or more sheets are overlapped and fed at once.
For documents that are loaded, the following conditions are required for overlapped documents to be detected
accurately.
● Paper weight: 50 to 209 g/m
2
(13.4 to 56 lb) (0.06 to 0.26 mm)
● Do not punch holes within 80 mm (3.15 in.) over the center of the document.
Refer to Fig. 1 in Area Not to Be Perforated (page 57).
● Do not attach other documents with glue or other adhesive within 80 mm (3.15 in.) over the center of the
document.
Refer to Fig. 1 in Area Not to Be Perforated (page 57).
ATTENTION
● The above condition applies when the document is set to the center of the pick roller width.
● Scanning a thick document such as a plastic card will always be falsely detected as overlapped documents.
In such a case, disable the setting in the image scanning application or scanner driver so that overlapped
documents are not detected, and then try scanning again.
HINT
The accuracy of detection for overlapped documents may drop depending on the document type.
Overlapping cannot be detected for the top 30 mm (1.18 in.) of a document in the feeding direction.
How to Load Documents
58

Fujitsu SP-1125N Specifications

General

Color scanning	Yes
Maximum scan size	210 x 297 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Scanner type	ADF scanner
Product color	Gray
Built-in display	No
Sensor type	CMOS dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	PDF
Daily duty cycle (max)	- pages
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input voltage	100 - 240 V
Power supply type	AC
Power consumption (off)	0.3 W
Power consumption (sleep)	2 W
Power consumption (typical)	18 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	135 mm
Width	298 mm
Height	133 mm
Weight	2500 g
