Replacing the Roller Set
The roller set consists of a brake roller and a pick roller.
Replace each roller in the following procedure.
1 Remove all documents from the ADF paper chute (feeder).
2 Open the ADF.
For details, refer to How to Open the ADF (page 34).
CAUTION
When the ADF is open, it might close accidentally. Be careful not to get your fingers
caught.
3 Remove the brake roller.
a Press the cover bushing of the brake roller to open the cover in the direction of the arrow.
Replacing the Consumables
79

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu SP-1125N and is the answer not in the manual?

Fujitsu SP-1125N Specifications

General IconGeneral
Color scanningYes
Maximum scan size210 x 297 mm
Output color depth24 bit
Output grayscale depth8 bit
Output monochrome depth1 bit
ADF scan speed (b/w, A4)25 ppm
Optical scanning resolution600 x 600 DPI
Scanner typeADF scanner
Product colorGray
Built-in displayNo
Sensor typeCMOS dual CIS
Scan driversISIS, TWAIN
Scan file formatsPDF
Daily duty cycle (max)- pages
Maximum ISO A-series paper sizeA4
USB version3.2 Gen 1 (3.1 Gen 1)
Input voltage100 - 240 V
Power supply typeAC
Power consumption (off)0.3 W
Power consumption (sleep)2 W
Power consumption (typical)18 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesENERGY STAR
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth135 mm
Width298 mm
Height133 mm
Weight2500 g
