Fujitsu SP-1125N User Manual

7 Select [USB] and connect the scanner to the computer as follows.
a Connect the scanner to the computer by using the USB cable that is supplied ( ).
b Connect the power cable to the scanner and the AC outlet ( , ).
c Turn on the scanner.
For details, refer to How to Turn the Power ON (page 31).
8 Click the [OK] button in the [How to Connect the Scanner] window.
9 Click the [Exit] button in the [SP Series Setup] window.
10 Start an image scanning application, and select the scanner to be used for scanning.
The scanner name depends on the scanner driver type and the scanner connection method.
Select the scanner name that is used for a USB connection. For details, refer to the help for the scanner driver.
11 Check whether the scanner is ready to start scanning.
For details, refer to How to Perform a Basic Scan (page 39).
Scanner Setup
30

Fujitsu SP-1125N Specifications

General

Color scanning	Yes
Maximum scan size	210 x 297 mm
Output color depth	24 bit
Output grayscale depth	8 bit
Output monochrome depth	1 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Scanner type	ADF scanner
Product color	Gray
Built-in display	No
Sensor type	CMOS dual CIS
Scan drivers	ISIS, TWAIN
Scan file formats	PDF
Daily duty cycle (max)	- pages
Maximum ISO A-series paper size	A4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input voltage	100 - 240 V
Power supply type	AC
Power consumption (off)	0.3 W
Power consumption (sleep)	2 W
Power consumption (typical)	18 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	135 mm
Width	298 mm
Height	133 mm
Weight	2500 g
