Chapter 1
Component Names and LED Names
This chapter provides the component names of the ETERNUS AF.
1.1 Controller Enclosures
An operation panel is in the front of the controller enclosure. The controllers and the power supply units are
installed in the rear.
1.1.1 Front
This section provides the names of the components in the front of a controller enclosure.
● With a Front Cover
Figure 1.1 Front View of a Controller Enclosure (with a Front Cover)
12
3 3
1. Operation panel
2. Front cover
3. Flange cover
12
