Specifications
Models VMP 40 49.5 50 60 80 100
Unit Horsepower 40 49.5 50 60 80 100
Boiler Connections
Steam Outlet 15 PSI IN 4 4 4 4 6 6
150# Flanged MM 101 101 101 101 152 152
Steam Outlet 150 PSI IN NPT 3 3 3 3 3 3
150# Flanged MM 76 76 76 76 76 76
Feedwater Inlet IN NPT 1 1 1 1 1 1.25
MM 25 25 25 25 25 31
Blowdown Outlet IN NPT 1.5 1.5 1.5 1.5 1.5 2
MM 38 38 38 38 38 51
Water Column Blowdown IN NPT 1 1 1 1 1 1
MM 25 25 25 25 25 25
Surface Blowdown IN NPT .75 .75 .75 .75 .75 .75
MM 19 19 19 19 19 19
Safety Valve 150 PSI Inlet IN NPT .75 1 1 1 1.25 1.25
MM 19 25 25 25 31 31
Safety Valve 150 PSIOutlet IN NPT 1 1.25 1.25 1.25 1.5 1.5
MM 25 31 31 31 38 38
Safety Valve 15 PSI Inlet (2)@ IN NPT 1.25 1.25 1.25 1.25 1.5 1.5
MM 31 31 31 31 38 38
Safety Valve 15 PSI Outlet (2) IN NPT 1.5 1.5 1.5 1.5 2 2
MM 38 38 38 38 51 51
Natural Gas Connection IN 1.5 1.5 1.5 2 2 2
MM 38 38 38 51 51 51
Burner Motor HP 5 5 5 5 5 7.5
KW 3.7 3.7 3.7 3.7 3.7 5.6
Approximate Weights
Shipping Weights (approx.) LB 6575 7375 7375 8170 8800 10300
KG 2982 3345 3345 3706 3992 4672
Operating Weight (approx.) LB 8659 9684 9684 10671 12051 14700
KG 3928 4393 4393 4840 5466 6668
Ratings Sea Level to
3000 FT. (914 M)
Output 1000 BTU/HR 1340 1656 1673 2009 2678 3347
1000 KCAL/HR 338 417 422 506 675 843
Steam Output** LBS/HR 1380 1708 1725 2070 2760 3450
KG/HR 626 775 783 939 1252 1565
Water Content GAL 172 274 242 270 383 518
LITERS 651 1038 916 1022 1450 1960
Approximate Fuel Consumption at Rated Capacity+
Natural Gas FT
3
/HR 1595 1972 1992 2392 3188 3985
M
3
/HR 45 56 56 68 90 112
Gas Pressure Required Min. IN W.C. 30 30 30 40 40 40
Gas Pressure Required Max. PSIG. 5 5 5 5 5 5
Electrical Requirements/Amps for Burner Motors
208V, 60 CY, 3 Phase 16.7 16.7 16.7 16.7 16.7 24.2
230V, 60 CY, 3 Phase 15.2 15.2 15.2 15.2 15.2 22.0
460V, 60 CY, 3 Phase 7.6 7.6 7.6 7.6 7.6 11.0
* Steam separator or dual steam nozzle design required. Consult factory for availability.
**Steam Output LB/HR - From 0 PSIG and at 212 Degrees F and KG/HR - From 0 KG/CM
2
and at 100 Degrees C
+Consumption based on natural gas 1000 BTU/FT
3
and 20 ppm NO
x
@ 3% CO
2
burner.
vmp40-100le-pds-2010-1008
The Fulton Companies
972 Centerville Road
Pulaski, New York 13142
Call 315-298
.
5121
Fax 315-298
.
6390
www.fulton.com
12a VMP IOM
