Furuno COLOR VIDEO PLOTTER 1833C - Page 14

xii
Two-unit NavNet system
Radar Antenna Unit
OR
GPS Receiver GP-310B
Radar, plotter data
Radar, plotter data
Radar Antenna Unit
OR
GPS Receiver GP-310B
RADAR
or
PLOTTER
RADAR
or
PLOTTER
Two-unit NavNet system
Three-or-more-unit NavNet system (Max. 4 NavNet capable display units)
HUB
Network
Sounder
ETR-6/10N (option)
Radar Antenna Unit
OR
GPS Receiver GP-310B
Radar Antenna Unit
OR
GPS Receiver GP-310B
RADAR
or
PLOTTER
RADAR
or
PLOTTER
Sounder data
Radar data
Plotter data
Note: The picture disappears
10 seconds after the NavNet
cable is disconnected from a
"sub" NavNet display unit.
Three-or-more-unit NavNet system
