1. OPERATIONAL OVERVIEW
1-12
1.5.4 Selecting image source
When more than one network radar or network sounder is connected to the
equipment, you may select an image source for each as shown below. This is
not necessary when only one network radar or network sounder is connected.
1. Press the [DISP] key.
2. Press any soft key to show the following display.
▲
SELECT
SOURCE
EDIT
RETURN
IF THERE IS MORE THAN
ONE NETWORK RADAR OR
ECHO SOUNDER, YOU MAY
SELECT THE IMAGE
SOURCES FOR DISPLAY.
RADAR SOURCE
RADAR
- - -
SOUNDER SOURCE
SOUNDER
-
IP ADDRESS
172.031.003.003
HOST NAME
RADAR
- - -
Select source menu
3. Use the trackball to select RADAR SOURCE or SOUNDER SOURCE as
appropriate, then press the EDIT key.
RADAR SOURCE SOUNDER SOURCE
Radar source Sounder source
RADAR
- - -
SOUNDER
-
Radar source and sounder source windows
4. Use the trackball and alphanumeric keys to enter source name: Adjust the
trackball to select location and enter character with the alphanumeric keys.
5. Push the [ENTER] knob to set.
6. Press the [DISP] key to finish.
7. Turn the power off and on again.
Note: Source names are determined at installation. For example, the source
names for radars in a two radar system might be “RADAR” and
“RADAR1”.
