1. OPERATIONAL OVERVIEW
1-8
1.4.2 Hue
You may select the colors for the radar, plotter and overlay displays as below.
1. Press the [POWER/BRILL] key momentarily.
2. Press the HUE soft key to show the hue setting window.
HUE
▲
¡ DAY
¡ NIGHT
¡ TWILIGHT
¤ MANUAL SET
▼
Hue window
3. Operate the trackball to select hue desired, referring to the table below.
MANUAL SET follows the color settings on the CHART DETAILS menu for
the plotter and the RADAR DISPLAY SETUP menu for the radar.
Night Day Twilight
Characters Red Black Green
Radar ring Red Green* Green*
Radar echo Orange Red Yellow
Background Black White Blue
Landmass (plotter) Light-Yellow Yellow Light-Yellow
* = Red on C-MAP display unit.
4. Hit the RETURN soft key to finish.
Note: When using the overlay screen, the own ship track will be hidden if the
radar background and own ship track are blue and the “MANUAL SET”
hue setting is used. In this case, set HUE to other position and then return
to “MANUAL” to show the own ship track in black.
