5. CUSTOMIZING YOUR UNIT
5-17
Contents of chart details menu for C-MAP (con’t from previous page)
Item Description Settings Default Setting
Bathymetric Line
Plotter/Overlay, Plotter,
Off
Plotter/Overlay
Spot Sounding
Plotter/Overlay, Plotter,
Off
Plotter/Overlay
Bottom Type
Plotter/Overlay, Plotter,
Off
Plotter/Overlay
Depth Area Limit
0-99999 ft
(m, fa, P/B)
20,164 ft (6, 50 m, 3, 27 fa,
4, 30 P/B)
DEPTH INFO
soft key
(See below.)
Bathymetric Range
0-99999 ft
(m, fa, P/B)
0-33 ft (0-10 m, 0-6 fa,
0-6 P/B)
Settings description
Basic: Shows basic characteristics of objects.
Detailed: Shows detailed characteristics of objects.
Multiple: Shows multiple icons for complex objects.
Off: Turns item off.
On: Turns item on.
Plotter: Shows item on plotter display.
Plot/No Sector: Shows item on plotter display. Sector not shown.
Plotter/Contour: Shows contour on plotter display.
Plotter/Overlay: Shows item on plotter and overlay displays.
Single: Shows single icon for complex objects.
DEPTH INFO soft key
1. Press the [MENU] key.
2. Press the CHART SETUP and CHART DETAILS soft keys.
3. Press the DEPTH INFO soft key.
DEPTH
INFO
EDIT
RETURN
BATHYMETRIC LINE PLOTTER/OVERLAY
SPOT SOUNDING PLOTTER/OVERLAY
BOTTOM TYPE PLOTTER/OVERLAY
DEPTH AREA LIMIT 00020, 00164ft
BATHYMETRIC RANGE 00000-00033ft
Depth info menu (C-MAP)
