4-2
Diplexer cover removed
Cavity resonator
Antenna base fixing screw
(Hex. socket head bolt :
M6 x 30 4 pcs.)
Figure 4-3 Cavity Resonator
Antenna base cover
Antenna fixing hole
(4xM6)
Figure 4-4 Antenna Base
