6.2 Description of Status Monitor Display
This section shows how to interpret the System Status Monitor.
File Edit Transmit EGC Reports Logs Options Setup Position StopAlarm
Date 97-12-24
Time 06:12 (UTC)
Position LAT 35:00.00N
LON 135:00.00E
Waypoint LAT
LON
Course DEG
Speed KTS
Current NCS 344 (IOR) LOGIN
Current Channel LES TDM
Current TDM LES TDM
MES Status Busy
GPS Status 3D
DCE Memory 32818 Bytes free
BBER
C/N
Send Level
RxIF AGC Level
REF Offset Freq
Synthe 1st-1 Local
1st-2 Local
RX2nd Local
Antenna Power Supply
Water Temperature
Water Current
Direction
Speed
Depth
Current State : TESTING SYNC (LES) 97-12-24 06:12 (UTC)
TESTING -- RECEVING MESSAGE NCS : IOR LOGIN LAT : 35:00.00N
DCE Ver 0x Oct - 199x LON : 135:00.00
000
OK (38dB)
OK ( 0)
OK (133)
OK ( 0Hz)
OK
OK
OK
OK
DEG
DEG
KTS
Interpreting the Status Monitor Display
Date: Current date
Time: Current time
Position: Vessel's position (either manual entry or automatic input by
navigation aid)
Waypoint: Position of waypoint selected on navigation aid
Course: Heading
Speed: Ship's speed
Current NCS: NCS which your vessel is logged in with
Current Channel: Channel in use, such as NCS common channel, MES message
channel etc.
Current TDM: Current TDM (NCS Commom TDM or CES TDM)
MES Status: Operational status of MES
