27
Initial Set-Up
(Set-Up Procedure When Installed In a Car)
When installing the servos in a car, performing function set-up in the following order
is recommended.
1. Set up the servo trims (page 23).
2. Set the servo direction of operation using the Reverse
function. (Page47)
The servo installation method and linkage direction depend
on the kit. Therefore, the servo operation direction may have
to be reversed relative to transmitter operation. Before in-
stalling the servo, check the operating direction and set it us-
ing the Reverse function.
3. Set the subtrim and adjust the servo neutral point.
(Page46)
4. Set the trigger travel by adjusting the throttle trigger me-
chanical ATL to your liking. (Page17)
5. Set EPA of each channel and adjust the servo throw
(travel). (Pages30)
To Next Page
