RECEIVER AND SERVO CONNECTIONS
Receiver
Output and
Channel
Aircraft (
ACRO
)
1 ailerons/aileron-1
1

2
2 elevator
3 throttle
4 rudder
5 spare/landing gear/aileron-2
1,3

2,3
6 
2
7 spare/aileron-2
1
8 spare/elevator-2
4
/mixture control
1
Aileron Differential mode (
AILE-DIFF
).
2
Flaperon mode.
3
Using Second Aileron option, second aileron servo output is sent to channels 5 and 6. (
AILE-2
)
4
AILEVATOR
(dual elevator) mode.
Receiver
Output and
Channel
Helicopter (
HELI
)
1 aileron (cyclic roll)
2 elevator (cyclic pitch)
3 throttle
4 rudder
5 spare/gyro
6 pitch (collective pitch)
7 spare/governor
8 spare/mixture control
(Swash Type)
(Normal linkage type)
H-1:each servo linked
to the swashplate
independently.
$,/؟$LOHURQ6HUYR
(/(؟(OHYDWRU6HUYR
3,7؟3LWFK6HUYR
(Wing Type)
(Tail Type)
()
()
ACRO
(FLAP)
()
ACRO
(FLAPERON)
()
()
()
(NOR AL)
()
(A L A OR)
()
()
(AL)
()
()
