F
EATURES
C
ONTENTS
Your GY701 includes the following components:
Type of set
• Gyro & Governor set w/BLS251
• Gyro & Governor set
• Governor set
• Gyro set
SET CONTENTS
GY701 Control Amp
*Mini Screwdriver
*Dust Covers (x3)
X X X X
Gyro Sensor
*Mounting Pads (x3)
X --- X X
Governor Sensor
*Sensor Mounting Hardware
*Magnet (x2)
--- X X X
BLS251 Servo
*Servo horn and mounting parts
--- --- --- X
Extensions (Black/Red)
1 1 2 2
X: supplied ---: not supplied
• Gyro section
• Advanced and adaptive PID operation is utilized
• Small and low prole gyro sensor. 2 colors LED are
installed on the top surface. Using the Aluminum
Alloy metal case. 21 x 21 x 8mm, 14.5 g
• Wide operation dynamic ranges up to +/- 1,200
deg/sec.
• 3 kinds of servo type are supported
• 3D and F3C operation mode is selectable
• The Feed forward operation is utilizing. Pitch sig-
nal can be added to the gyro operation.
• New operation algorism achieves the more consis-
tent pirouette and smooth Yaw control .
• Governor section
•Advanced and adaptive PID operation is utilized
•Fastest operation.
•Wider revolution control ranges, 1000 rpm-3000
rpm
•Both digital and analog servo can be selected
•Revolution compensation by Yaw rate is installed
•Governor or Rev. Limit mode selectable
•New operation algorism achieves more faster and
smooth revolution control .
•Back plate sensor can be selected by the option (for
OS-91, OS-55, OS-50)
• Other function
• Maximum revolution memorize
• Engine runtime integration
• OLED power saving
• LED on/off selectable
