AMP-43547 (-D3547, -D3527): 600W Configurable Servo Amps/Stepper Drives
This amplifier is unique in that it can run either servo or stepper motors on any axis.
The AMP-43547 (4-axis) and AMP-43527 (2-axis) are sinusoidally commutated, 16 bit PWM amplifiers for driving
brushless and brush-type servo motors. The AMP-43547 can also be configured by the user as 1/256 microstepping
drives for operating two-phase bipolar stepper motors.
The AMP-43540/43527 are capable of providing 600 watts of continuous power per axis. The AMP-43547/43527
drive modules are enclosed in the metal enclosure of the DMC-40x0. The standard amplifier accepts DC supply
voltages from 20-60 VDC.
AMP-43640 (-D3640): 20W Sinusoidally Commutated Linear Amplifiers
The AMP-43640 (4-axis) provides four linear drives for sinusoidally commutating brushless motors. It is capable of
providing 20 watts per axis, 80 watts total. The AMP-43640 drive modules are enclosed in the metal enclosure of
the DMC-40x0. The standard amplifier accepts DC supply voltages from 15–40VDC.
AMP-43740 (-D3740): 1200W Sinusoidally Commutated Amplifiers
The AMP-43740 (4-axis) is a sinusoidally commutated, 16 bit PWM amplifier for driving brushless and brush-type
servo motors. It is capable of providing 1200 watts of continuous power per axis. The AMP-43740 drive modules
are enclosed in the metal enclosure of the DMC-40x0. The standard amplifier accepts DC supply voltages from 20-
60 VDC.
SDM-440x0 (-D4040,-D4020): Microstepping Stepper Drives
The SDM-44040 (4-axis) and SDM-44020 (2-axis) are configurable (full, half, 1/4 and 1/16) microstepping drives for
operating two-phase bipolar stepper motors. They are capable of providing a selectable current of 0.5, 0.75, 1.0,
and 1.4 Amps/Phase per axis. The AMP-44040/44020 drive modules are enclosed in the metal enclosure of the
DMC-40x0. The standard amplifier accepts DC supply voltages from 12-30 VDC.
SDM-44140 (-D4140): Microstepping Stepper Drives
The SDM-44140 (4-axis) is a 1/64 microstepping drive for operating two-phase bipolar stepper motors. It is capable
of providing a selectable current of 0.5, 1.0, 2.0 and 3.0 Amps/Phase per axis. The AMP-44140 drive modules are
enclosed in the metal enclosure of the DMC-40x0. The standard amplifier accepts DC supply voltages from 20-60
VDC.
CMB-41012 (-C012): Communications Board (Single Ethernet Port)
The CMB-41012 provides the connections for the Ethernet and serial communication. It also breaks out the
Extended I/O into a convenient D-sub connector for interface to external devices.
CMB-41022 (-C022): Communications Board (Dual-Ethernet Ports)
The CMB-41012 provides Dual-Ethernet ports and serial communication. It also breaks out the Extended I/O into a
convenient D-sub connector for interface to external devices.
Chapter 5 Integrated Components ▫ 18 DMC-40x0 UL Installation Manual
