AMP-43547 (-D3547, -D3527)
Description
The AMP-43547 is a sinusoidally commutated, 16 bit PWM amplifier that can also be configured as a microstepping
drive. This amplifier is unique in that it can run either servo or stepper motors on any axis. The AMP-43547 can be
configured for all of the motors below with just a few commands.
• Brushless Motors
• Brushed Motors
• Stepper Motors
• 2PB Motors
WARNING
Do not “hot swap” the motor power or supply voltage power input connections. If the amplifier is
enabled when the motor connector is connected or disconnected, damage to the amplifier can
occur. Galil recommends powering the controller and amplifier down before changing the connector,
and breaking the AC side of the power supply connection in order to power down the amplifier.
Chapter 5 Integrated Components ▫ 26 DMC-40x0 UL Installation Manual
