Galil Motion Control DMC-40 0 Series Installation Manual

ICM-42100 (-I100)
Description
The ICM-42100 (-I100) option resides inside the DMC-40x0 enclosure and accepts sinusoidal encoder signals in
addition to standard, differential quadrature encoder signals
1
. The -I100 board can provide interpolation for up to
four 1 V
pk-pk
differential sinusoidal encoders resulting in a higher position resolution.
For more information regarding the Amplifier Enable Operation, see Chapter 3 of the DMC-40x0 User Manual.
Chapter 5 Integrated Components▫ 47 DMC-40x0 UL Installation Manual
