G&D DP-HR-CPU User Manual

User module »DP-HR-U-CON-Fiber«
115 · Target and user modules (DP-HR-U)
Technical data
DP-HR-U-CON-FIBER
Interfaces to
console:
Video: 1 × DisplayPort
Keyboard and mouse signals: 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack socket
USB 2.0: 4 × USB-A socket
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission to
the matrix switch
Interface: 1 × LC-Duplex socket
Transmission distance:  DVI-CPU-Fiber(M)
Max. 100 Meter (62,5μ/125μ),
Max. 200 Meter (50μ/125μ OM2)
Max. 400 Meter (50μ/125μ OM3)
 DVI-CPU-Fiber(S)
Max. 5.000 Meter (9μ/125μ OS1)
 DVI-CPU-Fiber(S+)
Max. 10.000 Meter (9μ/125μ OS1)
Video Format: DisplayPort (DP 1.1a)
Colour depth: 24 bit
Video bandwidth: 25 to 300 MP / s, DisplayPort 4 Lanes,
HBR 2.7 Gbps
Max. resolution:  2560 × 1600 (60 Hz)
 4096 × 2160 (30 Hz)
Examplary resolutions:  4096 × 2160 (24, 25 or 30 Hz)
 3840 × 2160 (24, 25 or 30 Hz)
 2048 × 2160 (60 Hz)
 2048 × 2048 (60 Hz)
 1920 × 1080 (50 or 60 Hz)
 1440 × 576i (50 Hz)
 1440 × 480i (60 Hz)
 Further standardised resolutions
within the video bandwith possible.
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio
 DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
