Target module »DP-HR-U-CPU-DH-UC«
Target and user modules (DP-HR-U) · 60
Target module »DP-HR-U-CPU-DH-UC«
With the DP-HR-U-CPU-DH-UC target module you can connect a computer with up to
two
DisplayPort graphics outputs (dual monitor) to two different digital matrix
switches of the ControlCenter-Compact, ControlCenter-Digital or the DVICenter series by
using one cable only.
Users at the consoles of the matrix switch can access the target module and operate
the connected computer.
The data stream of the USB devices connected to the active user module (DVI-U-CON,
DP-U-CON and DP-HR-U-CON series only) is transmitted to the computer with up to 16
Mbit/s.
Package contents
1 × Target module DP-HR-U-CPU-DH-UC
2 × DisplayPort video cable (DP-Cable-M/M-2)
1 × USB device cable
2 × Audio cable
1 × Power pack (12V/2A, only with variants incl. PowerPack)
1 × Power cable (only with variants incl. PowerPack)
1 × EasyStart flyer
1 × »Safety instructions« flyer
Required accessories
2 × Category 5e (or better) twisted pair cables to connect the target module to
two different matrix switches
ADVICE:
If you use the first video channel only, you are able to display resolutions
up to 4096
× 2160 @ 30 Hz (4K). Using both video channels allows resolutions up
to 1920
× 1200 @ 60 Hz. Detailed information about the supported resolutions is
given in the chapter
Technical data on page 64.
IMPORTANT:
At consoles with one monitor only, the image of the computer’s sec-
ond video output is not displayed.
