User module »DP-HR-U-CON-Fiber«
Target and user modules (DP-HR-U) · 110
User module »DP-HR-U-CON-Fiber«
With DP-HR-U-CON-Fiber user modules, you can connect a console (DisplayPort moni-
tor, keyboard, mouse and audio devices) to a digital matrix switch of the Control-
Center-Compact or ControlCenter-Digital series.
At the installed console, matrix switch users can access a target module to operate
the connected computer.
The data stream of the connected USB devices is transmitted to the active target
module with up to 16 Mbit/s (
DVI-U-CPU, DP-U-CPU, DP-HR-U-CPU and VGA-U-CPU series
only).
Package contents
 1 × DP-HR-U-CON-Fiber user module
 1 × Power cable
 1 × EasyStart flyer
 1 × »Safety instructions« flyer
Required accessories
 1 × Compatible optical fibre cable to connect the user module to the
matrix switch
NOTE: This user module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires CCD-I/O 16-Card-Fiber).
IMPORTANT: Both, the user module and the fiber ports are available as single-mode
variants or as multi-mode variants. Make sure that the port at the user module, the
-
fiber port and the optical fibers are compatible with each other.
