Enabling/disabling the target module’s Generic HID mode
Target and user modules (DP-HR-U) · 176
4. Select Generic HID and press F8 to select one of the following options:
5. Press F2 to save your changes.
Enabling/disabling the target module’s
Generic HID mode
USB target modules support different USB input devices. You can use the special
features of a USB input device after selecting the specific USB keyboard mode
(see
page 175).
As an alternative to the specific USB keyboard modes, you can use the Generic HID
mode. In this mode, data of USB devices connected to the Generic interface remains
unaltered when transmitted to the active target module.
How to select a USB keyboard mode:
1. Press Ctrl+Num (default) to open the on-screen display.
2. Press F11 to open the Configuration menu.
3. Select Target and press Enter.
4. Select the target module whose settings you want to change and press F5.
off:
Connect either a USB keyboard or a USB mouse to the user module’s
Generic interface.
on:
The data of any USB input device connected to the user module’s
Generic interface remains unaltered when transmitted to the active tar-
get module.
IMPORTANT:
To use the generic HID device, enable the USB HID mode
Generic HID of the target modules you want to access (see below).
IMPORTANT:
When connecting a USB hub or a USB composite device containing
multiple USB devices, only the first of the connected HID devices can be used in
Generic HID mode (see page 175).
