User module »DP-HR-U-CON-Fiber-DH«
Target and user modules (DP-HR-U) · 158
User module »DP-HR-U-CON-Fiber-DH«
With DP-HR-U-CON-Fiber-DH user modules, you can connect up to two DisplayPort
monitors (dual-monitor), keyboard, mouse, microphone and speakers to a digital
matrix switch of the ControlCenter-Compact or ControlCenter-Digital series by using one
cable only.
At the installed console, matrix switch users can access a target module to operate
the connected computer.
The data stream of the connected USB devices is transmitted to the active target
module of the
DVI-U-CPU, DP-U-CPU or DP-HR-U-CPU series with up to 16 Mbit/s.
When using the console to access a target module connected to a dual-head com-
puter, the monitors display the separate images of the graphics outputs. When
accessing a target module with one graphics input only, only the first monitor dis
-
plays an image.
Package contents
1 × User module DP-HR-U-CON-Fiber-DH
1 × Power cable
1 × EasyStart flyer
1 × »Safety instructions« flyer
NOTE:
This user module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires
CCD-I/O 16-Card-Fiber).
IMPORTANT:
Both, the user module and the fiber ports are available as single-mode
variants or as multi-mode variants. Make sure that the port at the user module, the
-
fiber port and the optical fibers are compatible with each other.
ADVICE:
If you use the first video channel only, you are able to display resolutions
up to 4096
× 2160 @ 30 Hz (4K). Using both video channels allows resolutions up
to 1920
× 1200 @ 60 Hz. Detailed information about the supported resolutions is
given in the chapter
Technical data on page 164.
NOTE:
Accessing a target module occupies the entire back channel (including Micro In
and USB 2.0 signal). Hence, these signals are not provided to the user modules that
access the channel at a later point (multi user operation).
