User module »DP-HR-U-CON-Fiber-MC2«
Target and user modules (DP-HR-U) · 128
Transmission 2|Tx: Insert the LC plug of a compatible optical fibre cable. Connect the
other end of the cable to the
Rx interface of another Dynamic Port provided at the
matrix switch.
Transmission 2|Rx: Insert the LC plug of a compatible optical fibre cable. Connect the
other end of the cable to the
Tx interface of the same Dynamic Port provided at the
matrix switch.
Power supply
Main Power: Connect the supplied power cable. Insert the cable’s Schuko plug in a
power socket.
Red. Power: Connect the connection cable of a compatible power pack to provide the
user module with a second, redundant power supply.
Startup
Turn on the user module after its installation.
Use the Main Power power pack or a redundant power pack to establish the power
supply:
Turn on the Main Power power pack.
Use an optional power pack to supply the Red. Power socket with power.
Automatic channel grouping
When operating the user module for the first time, the matrix switch recognises the
main channel and the user module’s additional channel. The channels are automati
-
cally added to a channel group.
ADVICE:
You can also connect the user module directly to a compatible target
module.
NOTE:
You can adjust adjsut any channel groups that were created automatically
or manually. More information about channel groups is given in the separate
manuals of the matrix switch web applications.
