User module »DP-HR-U-CON-Fiber-MC4«
Target and user modules (DP-HR-U) · 142
DP-HR-U-CON-FIBER-MC4
Audio Transmission type: transparent, bidirectional
Resolution: 24 bits
Refresh rate: 96 kHz
Bandwidth: 22 kHz
USB Specification: USB 2.0
Transmission type: transparent
Transmission rate: Max. 16 Mbit/s
Main power supply Type: Internal power pack
Connector: 1 × IEC plug (IEC-320 C14)
Power input: 100 - 240 VAC; 0.6 A - 0.4 A
Redundant
power supply
Type: External power pack
Connector: 1 × Mini-DIN 4-Buchse
Power input: 12 VDC; 3.8A
Housing Material: Anodised aluminium
Dimensions (W × H × D): 435 × 44 × 210 mm
Weight: Approx. 2.3 kg
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, EAC, FCC Class B, RoHS
