User module »DP-HR-U-CON-2-DH«
Target and user modules (DP-HR-U) · 156
Technical data
DP-HR-U-CON-2-DH
Interfaces to
console
Video: 2 × DisplayPort
Keyboard/mouse signals 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack socket
USB 2.0: 4 × USB-A socket
Tradeswitch-LED: 1 × D-SUB 9 scoket
Data transmission to
the matrix switches
Interface: 2 × RJ45 socket
Transmission length: Max. 140 meters
Audio
DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Sampling rate: 96 kHz
Bandwidth: 22 kHz
Video Format: DisplayPort (DP 1.1a)
Colour depth: 24 Bit
Video bandwidth: 25 to 300 MP/s (Channel 1)
25 to 165 MP/s (Channel 2)
Max. 330 MP/s (total)
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
