G&D DP-HR-CPU User Manual

Target module »DP-HR-U-CPU-MC2-UC«
Target and user modules (DP-HR-U) · 26
Technical data
DP-HR-U-CPU-MC2-UC
Interfaces to
computer
Video: 2 × DisplayPort
Keyboard and mouse signals 2 × PS/2 socket
1 × USB-B
Audio: 2 × 3,5 mm jack plug
Date transmission to
matrix switches
Interface: 4 × RJ45 socket
Transmission distance: Max. 140 metres
Video Format: DisplayPort (DP 1.1a)
Colour depth: 24 bit
Video bandwidth: 25 to 300 MP / s, DisplayPort 4 Lanes,
HBR 2.7 Gbps
Max. resolution:  2560 × 1600 (60 Hz)
 4096 × 2160 (30 Hz)
Examplary resolutions:  4096 × 2160 (24, 25 or 30 Hz)
 3840 × 2160 (24, 25 or 30 Hz)
 2048 × 2160 (60 Hz)
 2048 × 2048 (60 Hz)
 1920 × 1080 (50 or 60 Hz)
 1440 × 576i (50 Hz)
 1440 × 480i (60 Hz)
 Further standardised resolutions
within the video bandwith possible.
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Audio
 DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Refresh rate: 96 kHz
Bandwidth: 22 kHz
USB Specification: USB 2.0
Transmission type: transparent
Transmission rate: Max. 16 Mbit/s
