Target module »DP-HR-U-CPU-Fiber«
33 · Target and user modules (DP-HR-U)
Audio Transmission type: transparent, bidirectional
Resolution: 24 Bit
Refresh rate: 96 kHz
Bandwidth: 22 kHz
USB Specification: USB 2.0
Transmission type: transparent
Transmission rate: Max. 16 Mbit/s
Power supply Type: Portable power pack (12 V/2 A)
Connector: 1 × Mini-DIN 4 socket
Power input: Max. 600 mA @ 12 VDC
Housing Material: Anodised aluminium
Dimensions (W × H × D): 105 × 26 × 164 mm
Weight: Approx. 400 g
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, EAC, FCC Class B, RoHS
DP-HR-U-CPU-FIBER
