G&D DP-HR-U-CPU - Page 105

Console module »DP-HR-U-CON-MC2«
Computer and console modules (DP-HR-U) · 100
USB Specification: USB 2.0
Transmission type: transparent
Transmission rate: Max. 16 Mbit/s
Main power supply Type: Internal power pack
Connector: 1 × IEC plug (IEC-320 C14)
Power input: 100 - 240 VAC; 0.6 A - 0.3 A
Redundant
power supply
 optional
Type: External power pack
Connector: 1 × Mini-DIN 4 socket
Power input: 2.6A @ 12 VDC
Housing Material: Anodised aluminium
Dimensions (W × H × D): Approx. 270 × 44 × 210 mm
Weight: Approx. 1.54 kg
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, UKCA, FCC class B, TAA, EAC, RoHS,
WEEE, REACH
DP-HR-U-CON-MC2
