Computer module »DP-HR-U-CPU-Fiber«
Computer and console modules (DP-HR-U) · 28
Computer module
»DP-HR-U-CPU-Fiber«
With DP-HR-U-CPU-Fiber computer modules, you can connect a computer with Dis-
playPort graphics output to a digital matrix switch of the ControlCenter-Compact or Con-
trolCenter-Digital series.
Users at the consoles of the matrix switch can access the computer module and operate
the connected computer.
The data stream of the USB devices connected to the active console module (DVI-U-
CON
, DP-U-CON and DP-HR-U-CON series only) is transmitted to the computer with up to
16 Mbit/s.
Package contents
 1 × Computer module DP-HR-U-CPU-Fiber
 1 × DisplayPort video cable (DP-Cable-M/M-2)
 1 × USB device cable
 2 × Audio cable
 1 × Power pack (12V/2A, only with variants incl. PowerPack)
 1 × Power cable (only with variants incl. PowerPack)
 1 × »Manual information« flyer
 1 × »Safety instructions« flyer
NOTE: This computer module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires
CCD-I/O 16-Card-Fiber).
IMPORTANT: Both, the computer module and the fiber ports are available as single-
mode variants or as multimode variants. Make sure that the port at the computer
module, the fiber port and the optical fibers are compatible with each other.
