Computer module »DP-HR-U-CPU-Fiber-DH«
Computer and console modules (DP-HR-U) · 66
Computer module
»DP-HR-U-CPU-Fiber-DH«
With the DP-HR-U-CPU-Fiber-DH computer module you can connect a computer with
up to two
DisplayPort graphics outputs (dual monitor) to a digital matrix switch of
the ControlCenter-Compact or ControlCenter-Digital series by using one cable only.
Users at the consoles of the matrix switch can access the computer module and operate
the connected computer.
The data stream of the USB devices connected to the active console module (DVI-U-
CON
, DP-U-CON and DP-HR-U-CON series only) is transmitted to the computer with up to
16 Mbit/s.
NOTE: This computer module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires CCD-I/O 16-Card-Fiber).
IMPORTANT: Both, the computer module and the fiber ports are available as single-
mode variants or as multimode variants. Make sure that the port at the computer
module, the fiber port and the optical fibers are compatible with each other.
ADVICE: If you use the first video channel only, you are able to display resolutions
up to 4096
× 2160 @ 30 Hz (4K). Using both video channels allows resolutions up
to 1920
× 1200 @ 60 Hz. Detailed information about the supported resolutions is
given in the chapter
Technical data on page 70.
ADVICE: At consoles with only one monitor, use the key combination
Alt+arrow right to switch to the video stream of the computer's second video output
(see page 185).
