Computer module »DP-HR-U-CPU-Fiber-UC«
Computer and console modules (DP-HR-U) · 34
Computer module
»DP-HR-U-CPU-Fiber-UC«
With DP-HR-U-CPU-Fiber-UC computer modules, you can connect a computer with Dis-
playPort graphics output to two different digital matrix switches of the ControlCenter-
Compact or ControlCenter-Digital series.
At the consoles of both matrix switches, users can access a computer module to
operate the connected computer.
The data stream of the USB devices connected to the active console module (DVI-U-
CON
, DP-U-CON and DP-HR-U-CON series only) is transmitted to the computer with up to
16 Mbit/s.
Package contents
 1 × Computer module DP-HR-U-CPU-Fiber-UC
 1 × DisplayPort video cable (DP-Cable-M/M-2)
 1 × USB device cable
 2 × Audio cable
 1 × Power pack (12V/2A, only with variants incl. PowerPack)
 1 × Power cable (only with variants incl. PowerPack)
 1 × »Manual information« flyer
 1 × »Safety instructions« flyer
NOTE: This computer module can be connected to a compatible fiber port of
ControlCenter-Compact matrix switches or ControlCenter-Digital matrix switches
(requires
CCD-I/O 16-Card-Fiber).
IMPORTANT: Both, the computer module and the fiber ports are available as single-
mode variants or as multimode variants. Make sure that the port at the computer
module, the fiber port and the optical fibers are compatible with each other.
