6.7 Connectors
The RTxxx packaging includes mating connectors for the power supply
input, digital outputs, 12V power output, and lighting output.
Should spare parts be required these can be obtained from Würth
(www.we-online.com), Farnell (www.farnell.com), or Newark
(www.newark.com). See the table below for further information.
Connector Description
Würth part
number
Supplier part
number
Power input 2W screw terminal
free socket, 5.08mm
691 351 500 002 Farnell: 1641952
Newark:19P1467
Trigger input 4W screw terminal
free socket, 3.5mm
691 361 100 004 Farnell:1841351
Newark: 16T1571
Lighting
output
4W screw termial
free plug, 5.08mm
691 348 500 004 N/A
12V output 2W screw terminal
free plug, 5.08mm
691 348 500 002 N/A
