GARDASOFT RT 20 Series - Setting the Internal Trigger Timer

RTxxx LEDlighting controllers - User Manual
Use the p and q buttons to select
the required value in steps of
0.01ms. Press the
SEL
button.
E-6
is displayed. Press the
SEL
button to enter time values from
1μs to 999μs.
Use the p and q buttons to select
the required value in steps of 1μs.
Press the
SEL
button.
9.8 Setting the internal trigger timer
You can set an internal trigger timer when the RT200 is in pulse mode.
When set, the RT200 triggers with the same delay and pulse width
already set up, as described in Section 9.6, Setting up pulsed
operation. External triggering remains unchanged.
Ensure the RT200 is set to pulsed operation. To set the period of the
internal trigger, press and hold SELfor one second and follow the
keystrokes below:
Use the
p
and
q
buttons to select
FrE
and
press the
SEL
button.
— 45 —
