Zone Type Terminology (Areas & Attributes)
When programming the zone types other zone attributes including area allocation may
be programmed within the same screen. Please refer to the breakdown of the Zone
programming screen below.
Zone Programming Screen
Zone Number
The Zone number currently being programmed.
Zone Type
The current Zone Type (refer to previous page for terminology.
Area(s)
Area(s) that the current zone is allocated to.
Zone Attribute
Attribute for current zone. Attributes available are:-
Remove-
Zone cannot removed (omitted) by the end user.
Rem+/Dk
Zone may be removed (omitted) by end user and is also Double
Knock.
Page 54
000=Ent/Ex A=
1234567 Rem -
Zone Number
Zone Type
Area(s) Zone is allocated to
Zone Attribute
GardTec 872
Areas, Zones & Output Types
