Zone Programming Tutorial
Below is a Zone Programming Tutorial that shows how a single zone is programmed.
This should be repeated for all zones that require programming.
1) With the display showing:-
2) Enter the Engineer code (1234 default)
The display will show:-
3) Press YES. The display will show:-
4) Press Yes. The display will show:-
5) Press Yes. The display will show:-
6) Enter the zone number you wish to program
e.g 1 followed by Yes. The display will show
for example:-
7) Press No. The display will show:-
8) Note the chevron has now appeared before
the Ent/Ex. This is the Zone Type, now press
No until the Zone Type you require is displayed.
A description of the Zone Types available is
given on page 53 in this manual
Page 86
< < < < UN-SET > > > >
01 Jan 00: 00: 01
Do you want to . .
Use ENGNR. Mode ?
Program . . . . _ _ _
Zones ?
Program Zone
Types ?
Enter Zone # _ _ _
001 = Ent/Ex A =
1 = Remove -
001 > Ent/Ex A =
1 = Remove -
