Page 25
490X Engineer’s Reference Guide
Comprehensive instructions on how to setup and program the Radio Expansion
are given in the document Hybrid Wireless Set-Up & Programming Guide
document number PR5588 supplied with the Radio Receiver.
33) Press Yes. The display will show:-
34) Press No. The display will show:-
35) Press No. The display will show:-
36) Press Yes. The display will show:-
Any 12Hr type zone(s) may be placed on Test. A Zone on Test will never trigger
an alarm or send a central station signal. If the Zone(s) fails the Test when the
system is Set the display will show Test Fail when the user Un-Sets the system.
After 20 successful Sets and Un-Sets the Zone(s) will be taken out of Test by the
system. (To reset a Test Failed display FULLY
Set then Unset the system).
37) If you do not wish to put a Zone(s) on Test press
Yes and jump to Step 43
Otherwise
38) Press No. The display will show:-
39) Enter the Zone number you wish to place on Test
followed by Yes.
The display will show for example:-
40) To add more Zone(s) to the Test repeat from
Step 38.
Program Radio
Functions ?
Program Zone
Wiring ?
Program Zone
Attributes ?
Test None
Test 003
Enter Zone # _ _ _
then +YES or -NO
