Page 26
490X Engineer’s Reference Guide
41) When you have finished adding Zones to Test
press Yes.
42) The display will show:-
Three Part Sets are available on the 490X control panel. Zones added to the PT-1
(Part 1) screen will be Removed (Omitted) when the system is Part 1 Set. Zones
added to the PT-2 (Part 2) screen will be Removed (Omitted) when Part Set 2 is
used. When Part Set 3 is used Parts 1 & 2 are combined and Removed (Omitted).
43) If you do not wish to enter PT-1 Zone press Yes
and jump to Step 47
Otherwise
Press No. The display will show:-
44) Enter the Zone number you require for PT-1
followed by Yes.
The display will show for example:-
45) To add more Zones to PT-1 repeat from Step 43
46) When you have finished adding Zones to PT-1
press Yes
47) The display will show:-
Pt-1 None
Pt-2 None
Pt-1 004
Enter Zone # _ _ _
then +YES or -NO
