Page 27
490X Engineer’s Reference Guide
48) If you do not wish to enter PT-2 Zone press Yes
and jump to Step 52
Otherwise
Press No. The display will show:-
49) Enter the Zone number you require for PT-2
followed by Yes.
The display will show for example:-
50) To add more Zones to PT-2 repeat from Step 47
51) When you have finished adding Zones to PT-2
press Yes
52) The display will show:-
Two Chime suites are available on the 490X control panel so for example you
would have the Front Door on Zone 1 programmed into Ch1 and the Rear Door
on say Zone 6 programmed into Ch2. When the system is Unset opening the
Front Door will produce a Chime. Opening the Rear Door will produce a different
Chime.
It should be noted that Chime must be programmed as On from the user mode.
Please refer to the User Manual for details.
Pt-2 005
Enter Zone # _ _ _
then +YES or -NO
Ch1 None
