21) Press No. The display will show:-
22) Press Yes. The display will show:-
23) Press No twice. The display will show:-
24) Enter the time you require as the Exit Time
(in seconds) followed by Yes.
The display will show for example:-
25) Use the No key to scroll through the
Setting Modes.
26) When the Setting Mode you Require is displayed
press Yes. The display will show:-
27) Press No. The display will show:-
28) Press Yes. The display will show:-
The Final Set Delay is a period of time in seconds after the expiry of the Exit
Time and is intended to allow any PIRs for example that are on the Exit Route to
settle before the system finally Sets. The majority of PIRs will settle within the
Default Time of 3 seconds but some may need a Final Setting Delay of up to 10
seconds.
Program Setting
for PART 3 set ?
Program Setting
Delay ?
Final Set Delay
= 03s
Program Setting
for PART 3 set ?
P3-Exit time =30s
=Set by TIME
P3-Exit time >_ _s
=Set by TIME
P3-Exit time =20s
>Set by TIME
