Garmin G1000 Cockpit Reference Guide for the Columbia 350/400
190-00567-01 Rev. A
SECTION 3 – ENGINE
INDICATION SYSTEM (EIS)
3-1
SECTION 3: ENGINE INDICATION
SYSTEM (EIS)
The Engine Instrument Display is displayed on the left
side of the MFD.
Columbia 400
Columbia 350
Figure 3-1 Engine Instrument Display
Cylinder Head
Temperature
Indicator
Exhaust Gas
Temperature
Oil Tempera-
ture Indicator
Aileron Trim
Slide Bar
Turbine Inlet
Temperature
Indicator
Manifold
Pressure
Gauge
Tachometer
Oil Pressure
Indicator
Fuel Flow
Indicator
Fuel Quantity
Indicator
Elevator Trim
Slide Bar
Indicates
Selected Fuel
Tank
Indicates
Selected Fuel
Tank
