Garmin GPSMAP 1243xsv User Manual

NMEA 2000 Settings
Select Settings > Communications > NMEA 2000 Setup.
Device List: Displays the devices connected to the network and allows you to set options for some transducers
connected using the NMEA 2000 network.
Label Devices: Changes the labels for available connected devices.
Naming Devices and Sensors on the Network
You can name devices and sensors connected to the Garmin Marine Network and the NMEA 2000 network.
1 Select Settings > Communications.
2 Select Marine Network or NMEA 2000 Setup > Device List.
3 Select a device from the list on the left.
4 Select Change Name.
5 Enter the name, and select Done.
Garmin Marine Network
The Garmin Marine Network allows you to share data from Garmin peripheral devices with chartplotters quickly
and easily. You can connect a device to the Garmin Marine Network to receive data from and share data with
other devices and chartplotters that are compatible with the Garmin Marine Network.
Select Settings > Communications > Marine Network.
Setting Alarms
CAUTION
The Beeper setting must be turned on to make alarms audible (Sounds and Display Settings, page164). Failure
to set audible alarms could lead to injury or property damage.
Navigation Alarms
Select Settings > Alarms > Navigation.
Arrival: Sets an alarm to sound when you are within a specified distance or time from a turn or a destination.
Anchor Drag: Sets an alarm to sound when you exceed a specified drift distance while anchored.
Off Course: Sets an alarm to sound when you are off course by a specified distance.
Boundary Alarms: Disables and enables all boundary alarms.
Setting the Anchor Drag Alarm
You can set an alarm to sound if you have moved more than an allowable distance. This is very useful when
anchoring overnight.
1 Select Settings > Alarms > Navigation > Anchor Drag.
2 Select Alarm to turn on the alarm.
3 Select Set Radius, and select a distance on the chart.
4 Select Back.
170 Device Configuration

Garmin GPSMAP 1243xsv Specifications

General

Display Resolution	1280 x 800 pixels
Display Type	WXGA display
Touchscreen	Yes
Keypad	Yes
Water Rating	IPX7
Antenna	Internal or external over NMEA 2000
Receiver	10 Hz
Garmin Marine Network Ports	2
NMEA 2000 Ports	1
NMEA 0183 Input Ports	1
NMEA 0183 Output Ports	1
Wireless Connectivity	Yes
J1939 Connectivity	Yes
BlueChart g3 Charts	Yes
LakeVü g3 Charts	Yes
Waypoints	5, 000
Routes	100
Track Log	50, 000 points; 50 saved tracks
Sonar Capabilities	Yes
CHIRP Sonar	Yes
ClearVü	Yes
SideVü	Yes
Traditional Sonar Frequency	50/77/83/200 kHz
ClearVü/SideVü Frequency	260/455/800 kHz
Weight	5.1 lbs (2.3 kg)
Mounting Options	Flush
Video Input Ports	1 BNC
Accepts Data Cards	microSD card
CHIRP Frequency	Low, High
Transmit Power	500 W (RMS)
Operating Temperature	-15°C to 55°C (5°F to 131°F)
Storage Temperature	-4°F to 158°F (-20° to 70°C)
Power Input	10-32 Vdc
