Specifications
GPSMAP 7x3 Specifications
Dimensions (W × H × D) 192.3 × 140.3 × 74.1mm (7
9
/
16
× 5
1
/
2
× 2
15
/
16
in.)
Dimensions with cover on bail mount (W × H × D) 200.2 × 156.3 × 101.2mm ( 7
7
/
8
× 6
1
/
8
× 4in.)
Clearance to next obstruction behind chartplotter 27.8mm (2in.)
Display size (W × H)
154.6 × 91.0mm (6
1
/
16
× 3
9
/
16
in.)
17.8cm (7.0in.) diagonal
Display resolution WSVGA, 1024 × 600 pixels
Weight 1.3kg (2.8lb.)
Compass-safe distance 35cm (13.78in.)
Max. power usage at 10Vdc
Non-sonar models: 17.6W
Sonar models: 35.9W
Typical current draw at 12Vdc
Non-sonar models: 1.08A
Sonar models: 1.18A
Max. current draw at 12Vdc
Non-sonar models: 1.45A
Sonar models: 2.96A
Temperature range From -15° to 55°C (from 5° to 131°F)
Material Polycarbonate plastic and die-cast aluminum
Water rating IEC 60529 IPX7
4
Input voltage From 10 to 32Vdc
Fuse 6A, 125V fast-acting
NMEA 2000 LEN @ 9Vdc 2
NMEA 2000 draw 75mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Wireless frequency 2.4GHz @ 18.3dBm max.
Memory card 2 microSD card slots; 32GB max. card size
4
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
Appendix 185

Garmin GPSMAP 1243xsv Specifications

General

Display Resolution	1280 x 800 pixels
Display Type	WXGA display
Touchscreen	Yes
Keypad	Yes
Water Rating	IPX7
Antenna	Internal or external over NMEA 2000
Receiver	10 Hz
Garmin Marine Network Ports	2
NMEA 2000 Ports	1
NMEA 0183 Input Ports	1
NMEA 0183 Output Ports	1
Wireless Connectivity	Yes
J1939 Connectivity	Yes
BlueChart g3 Charts	Yes
LakeVü g3 Charts	Yes
Waypoints	5, 000
Routes	100
Track Log	50, 000 points; 50 saved tracks
Sonar Capabilities	Yes
CHIRP Sonar	Yes
ClearVü	Yes
SideVü	Yes
Traditional Sonar Frequency	50/77/83/200 kHz
ClearVü/SideVü Frequency	260/455/800 kHz
Weight	5.1 lbs (2.3 kg)
Mounting Options	Flush
Video Input Ports	1 BNC
Accepts Data Cards	microSD card
CHIRP Frequency	Low, High
Transmit Power	500 W (RMS)
Operating Temperature	-15°C to 55°C (5°F to 131°F)
Storage Temperature	-4°F to 158°F (-20° to 70°C)
Power Input	10-32 Vdc
