GPSMAP 76Cx Owner’s Manual 1
GETTING STARTED
Unit Overview
Carry Lanyard
attachment slots
Battery compartment
cover
External Data/Auxilary
Power Port (under
weather cap)
Internal
antenna
Interface keys
Auxiliary GPS
Antenna Connector
(under weather cap)
Battery compartment
locking D-ring
USB connector port
(under weather cap)
GETTING STARTED > UNIT OVERVIEW

Table of Contents

Other manuals for Garmin GPSMAP 76Cx

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Garmin GPSMAP 76Cx and is the answer not in the manual?

Garmin GPSMAP 76Cx Specifications

General IconGeneral
AutoNo
Marine (chartplotters, sounders)Yes
Routes quantity50
Tracks quantity20
Number of waypoints10000
Form factorHandheld
CertificationRoHS
InterfaceUSB
GPS receiverSiRFstarIII
RS-232 ports1
Supported protocolsNMEA 0183
Display resolution160 x 240 pixels
Display number of colors256 colors
Display size (HxV) (imperial)1.6 x 2.2 \
Battery typeAA
Battery life (max)18 h
Number of batteries supported2
GPS accuracy - position10 m
GPS accuracy - velocity0.05 m/s
Operating temperature (T-T)-15 - 70 °C
Weight and Dimensions IconWeight and Dimensions
Depth30 mm
Width69 mm
Height157 mm
Weight218 g
