Gateway FX530 - Replacing the Heat Sink and Processor

CHAPTER 5: Upgrading Your Computer
72
www.gateway.com
6
Reconnect the power supply cables using
your notes from Step 2.
7 Replace the side panel by following the
instructions in “Replacing the side panel”
on page 55.
Replacing the heat sink and
processor
Tips & Tricks
You need a Phillips
screwdriver to replace
the heat sink.
To replace the heat sink and processor:
1 Remove the side panel by following the
instructions in “Removing the side panel”
on page 51.
2 For more stability, place your computer on
its side. To avoid scratching the case, place
it on a towel or other non-abrasive surface.
3 Remove the fan cover by squeezing the
top (1) and bottom (1), then pulling the
cover (2)out.
1
1
2
