CHAPTER 5: Upgrading Your Computer
74
www.gateway.com
(indicated by the absence of a pin hole in
the processor socket), then return the lever
to its locked position.
8 Place the heat sink on the system board,
then tighten the screws that secure it to the
system board.
9 Replace the fan cover.
10 Return your computer to its upright
position.
11 Replace the side panel by following the
instructions in “Replacing the side panel”
on page 55.
Replacing the I/O board
Tips & Tricks
You need a Phillips
screwdriver to replace
the I/O board.
To replace the front I/O board:
1 Remove the side panel by following the
instructions in “Removing the side panel”
on page 51.
2 Remove the front bezel by following the
instructions in “Removing the front bezel”
on page 53.
