CHAPTER 1: Upgrading Your Computer
66
9 Replace the fan cover.
10 Return your computer to its upright position.
11 Replace the side panel by following the instructions in
“Replacing the side panel” on page 48.
Replacing the I/O board
To replace the front I/O board:
1 Remove the side panel by following the instructions in
“Removing the side panel” on page 45.
2 Remove the front bezel by following the instructions in
“Removing the front bezel” on page 47.
3 Remove the screw that secures the front I/O assembly
to the computer, then remove the I/O assembly.
Tools
You need a Phillips screwdriver to replace the I/O board.
Screw
8511858.book Page 66 Monday, December 18, 2006 10:51 AM
