www.gateway.com
71
3 Disconnect any cables that are attached to any
expansion cards, noting their locations and orientation.
(You will reconnect the cables after you install the cards
on the new board.)
4 Remove the expansion cards by following the
instructions in “Adding or replacing an expansion card”
on page 68. You can slightly seesaw a card end-to-end
to loosen it, but do not bend a card sideways.
5 Remove the fan cover by squeezing the top (1) and
bottom (1), then pulling the cover (2) out.
1
1
2
8511858.book Page 71 Monday, December 18, 2006 10:51 AM
