GBA ST1 - 5.1.5 Calibration Error Codes

GBA Global Bill Acceptors GBA ST1 Operation Manual
Page 17 of 37 Astrosys International Ltd
September 2011
ST1 Operations Manual Rev 2.0
5.1.5 Calibration Error Codes:
Status / Fault Flash 1 Flash 2 Flash 3 Flash 4 Comments
Calibration aborted Red Red Red Red
Eeprom fault Red Red Green Green
Sensor Errors
Transmissive sensors If there is a problem, try cleaning
the lenses.
Wide Left Red Red Green Red
Wide Right Red Red Red Green
Middle Left Green Green Green Red
Middle Right Green Green Red Green
Narrow Left Green Green Red Red
Narrow Right Green Red Green Green
Reflective Sensors
Upper Right Green Red Green Red
Upper Left Green Red Red Green
Lower Right Green Red Red Red
Lower Left Red Green Green Green
Coupon Red Green Red Red
Other sensors
Optical Anti-String Gate Red Green Red Green
Magnetic Red Green Green Red
Front Left Sensor Red Green Green Orange
Front Right Sensor Red Green Red Orange
Other Errors
Length error Red Red Green Orange
Mechanical Gate problem Red Red Orange
Green
Paper feed fault Red Red Orange
Red Try reinserting the paper carefully
Paper length too short or
tacho fault
Red Green Orange
Red
Calibration paper skewed Red Orange
Green Orange
Paper was inserted at an angle
Calibration paper dirty Red Orange
Red Orange
Or crinkled. Use a new piece.
Program Cards
Error on program card Red Red Red Orange
Try reprinting the card
Program card not
supported
Red Orange
Orange
Green The program card function is not
supported by the ST1
Future Use Red Orange
Orange
Red
