7.0 ELECTRICAL INTERFACE SPECIFICATION
7.1 Power
7.1.1 Power Supply – 20-pin connector
Voltage: 12Volts DC +/- 10% Regulated
4
7.1.2 Power Supply – Optional MDB 6-pin Connector and Power Regulator
Voltage: 20 to 50 Volts DC
7.1.3 Power Consumption
Quiescent: 200mA
Validating: 800mA
Stacking: 700mA
Stalled: 1400mA
7.2 Signal Interface
7.2.1 20-pin connector
Open Collector outputs;
Maximum Open Voltage 40V
Maximum Sink Current 50mA @ 12VDC
Maximum Output Low Voltage: 0.4VDC
Minimum Output High Voltage: 2.4VDC
Input low level voltage: 0…. 1V
Input high level voltage: 3…..12V (typically 3… 5V)
Input pull up to 5V: 21K Ω
7.2.2 Optional MDB 6-pin Connector
This connector provides opto-isolated data communication lines, in accordance with the NAMA
MDB specification.
Maximum output low voltage: 1V @ 20mA
Maximum input idle level current: 0.5mA
Minimum input active level current: 5mA
Pull-up resistor on TX: none
Limiting resistor on RX: internal, 560Ω
7.2.3 USB Connector
The ST1 is compliant as a USB 2.0 full speed host or device and is fitted with a mini-AB socket.
4
For Power packs, 12vDC connection should be Centre Positive.
